EV Motor Shafts & Powertrains

Ramping capacities to 3.0 Mio EV motor shafts. Manufacturing noiseless EV powertrain gears.

EV Drivetrain Sourcing Partner

Srimukha is a key supply-chain partner to leading electric vehicle (EV) manufacturers. Srimukha’s dedicated EV motor vertical produces Hub Motor Shafts and Mid-Mount Motor Shafts, with all processes housed in our Chennai plants. By 2025, our annual EV motor shaft capacity will reach 3.0 million pieces.

Fully Integrated In-House Process Sourcing

To assure OEM-level quality, every stage of our EV shaft manufacturing is performed in-house:

Cold Forging & Near-Nett Shaping: Reduces waste and optimizes raw steel metallurgy using Knuckle Joint presses.
Advanced Machining: CNC Turing, keyway slot milling, deep hole drilling, and splined gear hobbing.
Hardening & Grinding: IPSEN SQF and CNC Cylindrical Grinding to hold concentricity runouts under 5 microns.

Noiseless EV Powertrain Gears

EV gearboxes run at high RPMs, making noise reduction a primary design criteria. Srimukha manufactures noiseless helical transmission gears, utilizing CNC Power Skiving and **CNC Gear Grinding / Honing** to eliminate post-heat-treatment tooth profile distortions.

Stator Sub-Assembly Capabilities

Srimukha executes stator sub-assembly teardown analyses to optimize copper winding volumes and slot patterns. Below is our design study comparison between a 250W Ampere Hub motor stator and a 1000W Khetan stator:

Stator Parameter

Ampere (250W)

Khetan (1000W)

Core OD Diameter

206.5 mm

207.3 mm

Core Width / Height

10.8 mm / 26.1 mm

11.2 mm / 25.68 mm

No. of Core Slots

48 Slots

Winding Copper Wire Dia

0.536 mm (12 stack)

0.526 mm (13 stack)

Bearing Type Sourced

6204 2RS

6004 RS

Srimukha Market Vision (2027)

As part of Srimukha’s 2027 vision, we aim to secure a **minimum 60% market share** in the domestic 2-wheeler and 3-wheeler EV motor shaft and powertrain segment. We are also investing in expanding our stator and rotor sub-assembly lines to deliver ready-to-mount EV motor blocks directly to OEM assembly lines.
